32A 22KW Basic Home EV Charging Station

Level 2 32A Fast Up To 22kW

Basic Home EV Charging Statior

The charger for you who prefer easy and safe charging. Just plu

in your car and we will do the rest!

·Input Rating:1-phase 230V±20%;3-phase 400V±20%

·Output Rating: 1-phase 7kW 32A;3-phase 22kW 32A

·Internal RCD: AC 30mA & DC 6mA IEC62955 & IEC61008 certifie

·Ingress Protection: IP55

·Shipping Dimensions: 500 x 383 x 198 mm; 500x 383x243mm

·Charging Interface:SAE J1772 & Type-2 cable/Type-2 socket/

T2S Socket with Shutter

·Mounting Type:Wall or Floor(pedestal supplied separately)

Make life safer

IOCAHI0-N is a simple yet functional electric vehicle charger. User

don't need to think about complicated configuration or installatio

and can always trust it's reliability.

IOCAH10-N also supports dynamic load balancing to protect loca

grid network from overloading and ensure the most efficient use

the available power between EV Chargers and other home

appliances. locharger load management hub "IOCLMP" is require

to connect to IOCAH10-N charger by RS485 wire for the

communication.CT connecting to IOCLMP would measure real-

time electrical usage, thus to output the maximum current

available for EV charging.
